Introduction.
Hi folks. These notes and algorithms are ones I have made for my own purposes in the past.
I've posted them here incase they may be of use or interest to others.
But now I'm also starting to write some notes etc. especially for this page
to add to the range of info available, begining with some info for new-commers to video game programming
( the first of which is on simple collision detection ).
Most of these are notes on geometry in the context of programming video games.
Some of them won't describe good or even correct methods of geometry, but instead describe dirty short cuts to arrive at quick approximations.
There are many ways to skin a cat, for example for some situations you could get the same result
with pythagoras or trigonometry, so don't assume any of these notes describe the only way to arrive at a solution,
it is best to look at a few different methods, from different sources, and choose the one most efficient
for your programming problem.
Sorry for the poor repoduction and low contrast of some of the notes and diagrams (which were in pencil).
I'll draw them-up on CAD or something when I get time.
First are listed some of my notes and then,
further down the page, some of my algorithms (most are written in C).
Feel free to use anything on this page in your own games...
if you find these notes or algorithms really useful for your game or project please put my name in the credits...
right down the bottom in teeny tiny small print will do fine. :-)
If you need to ask any questions, or you want ot say hi, please drop me an email. My email address.
TRIANGLES.
MATRICES.
MECHANICS.
MISCELANEOUS.
auto_arc_tan() (v1) Find the angle of a 2D line. Integer Version. (Uses an arctan emulation formula)
auto_arc_tan() (v5) Find the angle of a 2D line. Integer Version. (Uses an arctan look-up table)
sine_12() Find the sine and or cosine. Integer Version.
distance_2D() and length_2D() Integer Version. (Uses a look-up table).
fp_distance() and fp_length() Floating point Version. (Uses a emulation formula).
distance_to_chord() Find an unknown Non-Hypotenuse Length. Integer Version. (Uses a look-uptable).
distance_to_chord() Floating Point Version. (Uses a look-uptable).
extend_to_perpendicular() Make one vector perpendicular to an other. Integer version.
gradient_8_to_sine_8() and gradient_8_to_cosine_8(). Convert a Gradient to a Sine or Cosine. Integer Version.
integer_square_root2() Quick square root calculation.
rotate_2D_with_sine_and_cosine(). Rotate a Vector. Integer Version.
rotate_vector(). Rotate a Vector. Floaing Point Version.
Find Y rotation relative to the XY plane.
squared_chord_length_to_angle(). Integer Version. (Uses Emulation Formulae)
sphere_collision() intersphere collision detection.
draw_short_vectors() Draw (and rotate if required) an
array of vectors onto a bitmap.
small_random() Get a pseudo random number 0 to 255.
Simple Video Output From a dsPIC microcontroller.
Convert To and From Big Number Bases.
A Simple Bouncing Ball Program.
NOTES
COLLISION DETECTION, INTERSECTIONS, ETC.
Simple 2D collision Detection.
Find the Closest Points Between two 4D Lines. (NOTES10#)
Useful for collision detection with high-speed objects (if you consider the paths of two objects as two four dimensional lines).
Use in conjunction with NOTES4# below if your collision objects are spheres or circles on linear paths.
Calculate Where Two Spheres or Circles Collide. (NOTES4#)
If you know where along the travel of two spheres or circles they come closest to each other
(for example by using the method NOTES10# above) then you can use this approximation method to find where they
actually collide.
Determine Which of a Number of Points an Object Will Pivot On (NOTES5#)
Using Small Circles or Spheres in an Integer World. (NOTES20#)
Circles Colliding with Blocks. (NOTES21#)
(Reference for source code only -- not for viewing in its own right).
Calculate Where Two 2D Lines Intersect (using gradients). (NOTES8#)
This method uses line gadients and ratios thereof.
Calculate Where Two 2D Lines Intersect (using areas). (NOTES9#)
Convert an Isosceles Triangle into a Right Angled Triangle. (NOTES1#)
If you have an isosceles triangle ( or two vectors of equal length ) this shows a way of
finding the position along one of its sides where your would position the new perpendicular side
to form a right angled triangle.
Make Two Right Angle Triangles From a Low Triangle. (NOTES11#)
Approximation method only.
Triangles Within a Quadrant (NOTES12#)
(Reference for source code only -- not for viewing in its own right).
Step-by-Step Illustration of 3x3 Matrix Multiplication. (NOTES15#)
An Illustration of Applying a Matrix to a Vector to Transform it. (NOTES16#)
(Using a 3x3 matrix plus a translation row).
Illustration of Trigonomic Matrix Multiplication. (Notes17# and Notes18#).
Also see how sine and cosine are use in rotation matrices.
Rough 'Ball Park' Figures for the Moment of Inertia of a Person. (NOTES19#)
A Fully Rotatable and Translatable Moment of Inertia Calculation System. NOTES14#
How to emulate any object's MoI with spheres so that the MoI can be rotated and translated
up or down a complex hierachy of co-ordinate systems -- for example, for automatically calculating the MoI
of a human body with its limbs in any position with the advantage of being able to
use the same kind of transformation matrices that you would use to produce the graphics.
Line Foreshortening. (NOTES2#)
The formula for foreshortening a line depending on its angle of inclination from being face-on
to the viewer for upto 45 degrees ( pythagoras style ).
Sphere Quandrants (NOTES13#)
(Reference for source code only -- not for viewing in its own right).
Analogue Tea. (Notes22#)
Programmers need to take a minute to chill-out now and then. Clear your mind... reconnect to the cosmos.
ALGORITHMS
Items in the Algorithms section generally contain some form of program source code
(routines, functions, or even whole programs) that you could cut'n'past into your program...
some stuff you can use 'as-is' (especially the routines and functions) and other stuff will need
adapting because it is an extract from one of my programs and may, for example, reference global variables
not included.
This does a similar job to the standard C arctan2() function but if you're program uses integer arithmatic
(instead of floating point) then you may not have the equivelent integer function... so here is
one you could use. I've put a lot of comments in this version to make it easy to understand.
Same as the above routine, but it uses a look-up table rather than a formula to get the arc tangent values.
A simple routine that looks-up a sine and or cosine for an angle from a table of figures.
Find the distance between two 2D co-ordinates, or find the length of a 2D line (a vector).
Find the distance between two 3D co-ordinates, or find the length of a 3D line (a vector).
Find the distance from the centre of a circle to the centre of a chord line by supplying the chord length and the circle radius.
Alternatively this could be though-of as finding the unknown length of a side of a right angled triangle
when you know the opposite or adjacent side's length and the hypotenus's length.
Make one vector perpendicular (at 90 degrees) to another in 3D space, preserving the original
2D plane that the original vectors formed.
Normally you supply an angle to a sine or cosine function... but if you only know the gradient you can save
time by not having to calculate the angle first and use these functions instead.
For programs using integer maths, this routine calculates a quick square root (approximate) value for any signed 32bit value
specified.
Rotate a 2D vector ( or rotate a 3D vector about a single axis ) without using matrices.
Rotate a 3D vector about a single axis without using matrices.
Find the angle between two vectors in 3D space.... or in other words
find the apex angle of an isosceles triangle.
All numbers in the range are guaranteed to be returned after 512 calls.
You can use this program to convert a large integer number to a shorter, easier to remember, alpha-numeric figure.
A program that might be interesting to beginers. It is written in the freely available Yabasic language.
